Product

EMC7070

Product Features
● Using EMC resin, the product has high reliability;
● High brightness, the typical value of brightness is up to 640lm@Ra80;
● High efficacy, efficacy higher than 170lm/W@Ra80.
Applications
Suitable for street light, spotlight, high bay, flood light, landscape lighting, etc.20201019005012_22483.png



Part NumberPower (W)Luminous
Flux(lm)
VF (V) If (mA)RaCCT (K)Specification
E70701-W29GN2N5EM5M6-LX003.6500-70031-33115753000
E70701-W41GN3N6EM5M6-LX003.6550-75031-33115754000
E70701-W52GN3N6EM5M7-LX003.6550-75031-33115755200
E70701-W58GN3N6EM5M6-LC003.6550-75031-33115755800


Product Features
● Using EMC resin, the product has high reliability;
● High brightness, the typical value of brightness is up to 640lm@Ra80;
● High efficacy, efficacy higher than 170lm/W@Ra80.
Applications
Suitable for street light, spotlight, high bay, flood light, landscape lighting, etc.20201019005012_22483.png
